3536 10 Ton Hydraulic Cylinder Hoist Only Kit – 3.5" Bore × 36" Stroke

In stock
SKU: KIT-3536
$449.00
Free Shipping

Use this text to encourage communication or promote sharing on social networks.

You can also add links

3536 10 Ton Hydraulic Cylinder Hoist Only Kit – 3.5" Bore × 36" Stroke

Product Description

The 3536 10 Ton Hydraulic Cylinder Hoist Only Kit features the heavy-duty 3536 hydraulic cylinder with a 3.5" bore, 36" stroke, and 1.75" chrome-plated rod.

Rated for up to 3,000 PSI with a maximum cylinder force of 28,863 lbs, it is designed for compatible dump trailer, truck, agricultural, and industrial hydraulic applications.

The kit includes the hydraulic cylinder, upper and lower mounting brackets, and two mounting pins.

Key Features

  • 3536 heavy-duty hydraulic cylinder

  • 3.5" Bore × 36" Stroke

  • 1.75" Rod Diameter

  • 3,000 PSI Maximum Working Pressure

  • 28,863 lb Maximum Cylinder Force

  • Heavy-duty welded steel construction

  • Precision-honed cylinder tube

  • Ductile iron piston

  • Chrome-plated induction-hardened rod

  • Corrosion-resistant black finish

  • Includes mounting brackets and pins

What's Included

  • 1 × 3536 Hydraulic Cylinder

  • 1 × Upper Mounting Bracket

  • 1 × Lower Mounting Bracket

  • 2 × Steel Mounting Pins

Important Note

Hydraulic power unit, hoses, fittings, wiring, and controller are NOT included.

Technical Specifications

Specification Details
Cylinder Model 3536
Cylinder Type Single-Acting
Bore 3.5"
Stroke 36"
Rod Diameter 1.75"
Working Pressure 3,000 PSI
Maximum Force 28,863 lbs
Retracted Length 46.25"
Extended Length 82.25"
C Dimension 40.92"
Port SAE #8
Cylinder Weight 77 lbs
Color Black

Cylinder Construction

  • Rod: Induction-hardened steel, chrome plated

  • Piston: Ductile iron

  • Tube: Honed and precision-finished steel

  • Construction: Heavy-duty welded

  • Gland: Threaded

  • Seals: High-quality hydraulic seals

  • Finish: Corrosion-resistant black paint

Applications

Suitable for compatible hydraulic applications including:

  • Dump Trailers

  • Scissor Hoist Trailers

  • Gooseneck Trailers

  • Tilt & Load Trailers

  • Waste Management Equipment

  • Agricultural Equipment

  • Material Handling Equipment

  • Industrial Hydraulic Systems

Frequently Asked Questions

Q1: What is included in this kit?

The kit includes 1 3536 hydraulic cylinder, 2 mounting brackets, and 2 mounting pins.

Q2: Does this kit include a hydraulic power unit or hoses?

No. Hydraulic power unit, hoses, fittings, wiring, and controller are not included.

Q3: What are the main cylinder specifications?

The HCL3536 features a 3.5" bore, 36" stroke, 1.75" rod, 3,000 PSI maximum working pressure, and 28,863 lb maximum cylinder force.

Q4: Can this kit be used on a dump trailer?

Yes. It is suitable for compatible dump trailer and hydraulic hoist applications. Please verify dimensions and mounting requirements before purchasing.

Q5: Is this a complete hydraulic hoist system?

No. This is a cylinder and mounting-component kit only. Additional hydraulic components are required to complete the system.
